What is a digital pressure testing machine?
In the fields of industrial manufacturing, construction engineering and materials science, the digital pressure testing machine is a high-precision equipment widely used in testing the mechanical properties of materials. It uses digital technology to achieve precise measurement of materials' compression, tensile, bending and other properties, providing reliable data support for quality control and research and development. This article will introduce in detail the definition, working principle, application scenarios and current hot technology trends of digital pressure testing machines.
1. Definition of digital pressure testing machine
The digital pressure testing machine is a mechanical testing equipment that uses electronic sensors and computer control systems. It can automatically record and analyze the deformation, strength and other parameters of the material during the stress process. Compared with traditional mechanical testing machines, its core advantages areHigh precision,AutomationandData traceability.
| Comparative item | Digital pressure testing machine | Traditional mechanical testing machine |
|---|---|---|
| Accuracy | Within ±0.5% | ±2%-5% |
| data logging | Automatic storage, support export | Manual reading, no storage |
| Operational complexity | One-click testing, intelligent | Manual adjustment is required and takes a long time |
2. Core structure and working principle
The digital pressure testing machine mainly consists of the following modules:
| module name | Function description |
|---|---|
| Loading frame | Provide a rigid support structure to ensure uniform stress |
| Servo motor system | Precisely control loading speed and intensity |
| High precision sensor | Real-time monitoring of force value changes (the measuring range is usually 1kN-3000kN) |
| Data acquisition card | Convert analog signals to digital signals (sampling rate ≥ 100Hz) |
| control software | Supports GB, ISO, ASTM and other standard testing processes |
The workflow is: sample placement → parameter setting → automatic loading → real-time data collection → generate stress-strain curve → output test report.
3. Typical application areas
According to industry data analysis in the past 10 days, the demand for digital pressure testing machines has increased significantly in the following scenarios:
| Industry | Application cases | Test indicators |
|---|---|---|
| New energy vehicles | Pressure resistance test of battery pack structural parts | Ultimate bearing capacity, plastic deformation |
| 3D printing materials | Strength verification of new composite materials | Anisotropy ratio, elastic modulus |
| Smart construction site | Concrete test block cloud monitoring | 7-day/28-day intensity growth rate |
4. Technology development trends
Combined with recent hot technology trends, digital pressure testing machines are showing three major innovation directions:
1.AI empowerment: Automatically identify material fracture characteristics and predict failure modes through machine learning algorithms (such as Tesla’s latest metal material analysis patent)
2.IoT integration: Supports 5G remote monitoring, and test data is synchronized to the cloud database in real time (refer to Huawei Industrial Internet White Paper Case)
3.Miniature design: The weight of the desktop testing machine can be controlled within 80kg, meeting the needs of rapid on-site testing (new product data at the 2023 Hannover Industrial Show in Germany)
5. Precautions for model selection
When purchasing a digital pressure testing machine, you need to focus on the following parameters:
| Parameter category | Recommended value | Remarks |
|---|---|---|
| Force accuracy | ≤±0.5%FS | FS refers to full scale |
| Speed control accuracy | ≤±1% set value | Recommended closed loop control system |
| Software certification | CMA/CNAS certification required | Regarding the validity of the test report |
Among the current mainstream brands, the new generation products of manufacturers such as Meters, Shimadzu, and Hengzhun Instruments have achieved double breakthroughs in test speed (up to 500mm/min) and accuracy (level 0.3).
With the advancement of the smart manufacturing 2025 strategy, digital pressure testing machines are evolving from a single detection tool to an intelligent analysis system. Mastering its technical characteristics and application methods is of great significance to improving product quality and R&D efficiency.
